Ironstrike Montlake 230 GL Woodburning Insert
Ironstrike Montlake 230 GL Wood-burning Insert



Alternative Views:


Price: $2,477.00

Price with Selected Options: $2,477.00


Product Code: F3832


Select Top (One Required):


Select Surround to Complete Unit*:


Optional Accessories:
Decorative Trim - Nickel Face Plate (H8346) [Add $127.80]

Decorative Trim - Brushed Nickel Face Plate (H8347) [Add $127.80]

Decorative Trim - Brushed Nickel Louver For Cast Iron Top Only (H9138) [Add $108.90]

Decorative Trim - Stove Panel Bracket Kit (H9139) [Add $40.50]

Raised Hearth Cover Plate (H8675) [Add $183.60]

4" Flex Adapter (UZIAD) [Add $46.80]

Outside Air Kit - 4" I.D. X 10 ft long insulated flex (UZI) [Add $86.40]


Product Description Technical Specs Extended Information

The Lodge Collection wood-burning inserts have elegantly and efficiently raised the standard for home heating with their Thermal Fin Technology (TFT™). This cast-iron heat exchanger innovation delivers the best amount of warmth. The durable ceramic glass gives you unobstructed views of the fire and allows for easy heat transfer. This insert comes standard with a 2.3 cu.ft. combustion chamber, ceramic glass, interior brick and baffle, 150 CFM blower, air wash system and a 6" flue outlet. A wide set of options means that Lodge Collection inserts will easily complement any indoor setting. Call Obadiah's today for yours!

Features

  • Spacious 2.3 cubic foot firebox interior accepts up to 18” logs.
  • 76,000 BTU’s/hour and heats up to 1,200-2,200 square feet.
  • Thermal Fin heat exchanger creates 32% more surface area than a standard insert design resulting in more heat entering the room.
  • Air-boost timer automatically adjusts the air intake control making startup and reloading easier.
  • Tall opening provides and expansive view of the burning fire.
  • Ceramic glass for extra strength and optimum heat transfer.
  • Unique, integral air wash system keeps the glass clean and clear for a wide-open view of the fire.
  • Precision-cut, heavy-gauge steel provides dependable, long-lasting operation.
  • High-density firebrick retains heat longer, resulting in increased efficiency.
  • One-touch control ensures easy operation and comfort.
  • Dual 150-CFM variable-speed blowers quickly move heat from the insert into your room.
  • Choose from several sizes of surround panel kits to match your opening size (1-required)
  • Choose between a steel or cast-iron warming top (1-required). 8 1/8" depth of cook top.
  • Optional decorative door trim in Brushed Nickel or Nickel allow customization to your style.
  • EPA-certified and Washington State-approved for clean and efficient operation.
  • Limited Lifetime Warranty
*Square-feet heating capacities are approximations only. Actual performance may vary depending upon home design and insulation, ceiling heights, climate, condition and type of wood used, appliance location, burn rate, accessories chosen, chimney installation and how the appliance is operated.
Required Acessories:


Top (one Required)

  • Montlake 230 Steel Top (H8673)
  • Montlake 230 Cast Iron Top (H8674)


Surround Panels

  • Black - 26 1/2" X 41" (H8677)
  • Black - 26 1/2" X 48" (H8678)
  • Black - 31" X 41" (H8679)
  • Black - 31" X 48" (H8680)
  • Black Trimmable - 33" X 48" (H8681)


Optional Accessories:


Decorative Trim

  • Nickel Face Plate (H8346)
  • Brushed Nickel Face Plate (H8347)
  • Brushed Nickel Louver For Cast Iron Top Only (H9138)
  • Stove Panel Bracket Kit (H9139)




Outside Air Kits

  • Outside Air Coupler Kit (UZIAD)
  • Outside Air Ducting Kit (UZI)




Raised Hearth Cover Plate (H8675)
